Specification:
Origin: Mainland China
LCD Display: Displays Power, Settings, Delay, Voltage, Mode And Internal Temperature.
Continuous Spot Welding Mode: Supported
Power Setting Adjustment: 11 Levels
Battery Type: Lithium Polymer Battery
Battery Capacity: 2200mAh
Design Current: 600a (Maximum)
Input Interface: Type-C
Input Parameters: 5V/1A
Nickel Strip Thickness: 0.1-0.25mm
Casing Material: ABS
Size: About 186.00x44.00x20.00mm/7.32x1.73x0.79inch
Safety Precautions:
1. Please read the instruction manual carefully before using this product.
2. Once metal contact is detected, the welding head will be output and can be lifted for the next welding.
3. Make sure the welding surface is rust-free, clean and flat. Keep the nickel strip clean and flat. Press the spot welder correctly to ensure good contact between the welding needle, nickel strip and battery, and avoid hanging or poor contact to obtain the best welding effect. Different nickel strip thickness and power settings are not always associated with better results; users can experiment to find the most suitable settings.
4. Only Type-C chargers (5V/1A) can be used; do not exceed 5V. Simultaneous charging and use of the product are not supported.
Note:
Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
Please allow 1-2cm measuring deviation due to manual measurement.
