Specification:
Origin: Mainland China
DIY Supplies: ELECTRICAL
Material: PC
Color: black
Style: rectangular
Display: color digital display
Voltage measurement range: 3.30V~30.0V Resolution accuracy: 0.01V
Current measurement range: 0.00~5.10A resolution accuracy: 0.01A
Cumulative capacity range: 0~99999mAh resolution accuracy: 0.001Ah
Cumulative power range: 0~999999mWh resolution accuracy: 0.001Wh
Power measurement range: 000.00~150.00W resolution accuracy: 0.01W
Impedance measurement range: 1~999.9ohm resolution accuracy: 0.1 ohm
Temperature measurement range: 0~80 degrees Celsius 0~80 degrees Celsius resolution accuracy: 1 degree Celsius
Maximum timing time: 999 hours, 59 minutes and 59 seconds Resolution accuracy: 1 second
Timed charging reminder setting: countdown for 24 hours, any set value
USB D+ voltage range: 0V~2.999V resolution accuracy: 0.001V
USB D-voltage range: 0V~2.999V Resolution accuracy: 0.001V
The phone is fully charged to remind the threshold parameters: <2W/0.5 hours
Refresh time: >500mS/time>500mS/time
Measurement rate: about 0.5 times/second
Alarm method: siren sound + display prompt dual warning
Display type: micro-power LCD module LCM white font Chinese and English display
Self-consumption current: <0.02A
Working temperature: -10~+60 degrees Celsius
Working humidity: 10~80 (no doubt) 10~80 (no doubt)
Working air pressure: 80~106kPa
Product size: 60.00x60.00x10.00mm/2.36x2.36x0.39inch
Weight: 30g
Note:
Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
Please allow 1-2cm measuring deviation due to manual measurement.
