Specification:
Origin: Mainland China
Test parameters: L, C, R, D, Q, ESRD/0/Z
Diode test: Support
Basic accuracy: 0.5%
Equivalent circuit: series/parallel
Range mode: automatic
Test speed: 2 times/s
Test segment configuration: Kelvin test
Display: 1.14-inch color screen, resolution 240*135
Battery display: Support
Battery capacity: 300mA
Battery life: 5 hours
Test signal frequency: 100hZ/1KHz/10kHz
Test signal level: 0.6V/0.3V/0.1V RMS
Measurement range:
R: 0.01Ω-20.00MΩ
C: 0.01pF-999.9mF
L: 0.1μH-9999H
D,Q: 0.001-9999
Shell material: ABS
Product size: about 132.00x22.00x16.00mm
Product size: 5.2x0.87x0.63inch
Note:
Due to different monitor settings and lighting conditions, the actual color of the item may vary slightly from the pictures. Thanks for your understanding!
Please allow a 1-2 cm difference in measurements due to manual measuring.
Package Content:
1 x LCR Bridge Tweezer Meter
1x USB Cable
1 X English Instruction Manual
Selling point content
Mini Smart Bridge Tweezer LCR SMD ESR Tester Resistance Capacitance Inductance Diode Tester 100hZ/1KHz/10kHz Auto Multimeter Tools Smart LCR Bridge Tweezer Meter Measurement Tools
Feature:
1.High Precision Measurement: Achieve a basic accuracy of 0.5% to ensure reliable and precise results when using the Resistance Capacitance Inductance Diode Tester. Perfect for critical applications.
2.Multifunctional Testing: This LCR Meter Tweezer supports various parameter tests including inductance, capacitance, resistance, diode, and quality factor to meet diverse electronic component testing needs.
3.Rapid Testing Speed: With a test speed of 2 times per second, this Auto Multimeter Tools is ideal for fast-paced environments, significantly boosting efficiency.
4.Long Battery Life: Equipped with a 300mA battery capacity, this SMD Tester supports 5 hours of continuous use, perfect for extended outdoor or on-site testing tasks.
5.Automatic Range Selection: The ESR Meter auto-selects the measurement range, simplifying operation and improving testing efficiency across various scenarios.
